2017 Haro Group 1 RS1 frame & fork kit (1987 Vintage Series 20″)

2017 Haro Group 1 1987 Replica

BMX Products

2017 Haro Group 1 RS1 frame & fork kit (1987 Vintage Series 20″)

The legendary 1987 Haro Group 1 RS1 frame and fork is back!! That’s right the BMX racing kit that “Pistol” Pete Loncarevich made famous has returned as part of Haro’s 1987 Vintage Series. This repop of the 1987 Haro Group 1 comes as close to the original that Pistol Pete rode back in the day. Peep the specs below.

-100% 4130 Cr-Mo construction
-1987 Group 1 replica frame and fork geometry and features 1″ threaded fork and American size bottom bracket size
-Wrap-around head tube gusset
-Tapered seat/chain stays and fork legs
-Classic Black/Blue/Chrome finish
-This frame features 990 brake mounts! (Not pictured)
2017 Haro Group 1 1987 Replica side
-Top Tube- 19″ (Dam that’s short in comparison today’s adult BMX frame sizes!!! 🙂 )
-Rear Chainstay- 15″
-BB Height- 12″
-Head Tube Angle- 71.5
-Seat Tube Angle- 69 (Dang that’s laid back!! 🙂 )
-Weight- FRAME 4.9 lbs, FORK 1.8 lbs

PARTS SIZING LIST: (This frameset requires parts of the following sizing-)
-1″ threaded BMX headset
-American bottom bracket
-990-style rear brake
-7/8″ (22.2mm) seatpost
-1″ (25.4mm) seatpost clamp
-3/8″ standard BMX wheel axles

This frame is a legit blast from the past! It’ll be awesome to see them at the shows and hopfully on the tracks too in the near future.
